Description
Sleek simplicity describes the Kink Prophet frame. A no-frills, straight to the point, super-strong frame, that features all the modern specs and looks great while doing it. The modern but not extreme geometry makes this frame a stable and easy ride for just about anyone, and the custom designed gussets and stay bridges provide additional strength and stiffness. This frame comes standard with an integrated seat post clamp, integrated chain tensioners, and removable brake lugs for those looking to install brakes (mount kit sold separately).
Geometry
| Toptube Sizes | 20”, 20.5”, 20.75”, 21”, 21.25” |
| Chainstay Length | 13.25” – 13.5” |
| Bottom Bracket Height | 11.6″ |
| Standover Height | 8.75″ |
| Headtube Angle | 75° |
| Seattube Angle | 71° |
| Headtube Height | 5″ |
Tech Spec
| Material |
100% Seamless 4130 Chromoly Tubing |
| Headtube | Integrated Campy Spec |
| Dropouts |
Laser Cut with Integrated Chain Tensioners |
| Bottom Bracket | Internally and Externally Machined Mid Size BB |
| Braking | Removable Through-Bolt Brake Mount System |
| Particulars | Toptube and Downtube Gussets Widened Stays for Big Tire Clearance Integrated Seat Post Clamp Custom Formed Seatstay and Chainstay Bridges |
| Weight | 5lb 7oz (20.5″) |
