Description
Colour: Gloss Sand
Top Tube Length: 21”
Frame: Cromo Top Tube , Welded Brake Mounts, Integrated Head Tube, Mid Bb, Cnc Seat Stay Bridge Embossed Logo Down Tube Gusset
Geo: Ht: 74.5° / Cs: 13.25” / So: 8.5” / Bb: 11.6” / St: 71°
Forks: Cromo Steerer Tube, Integrated Bearing Race, Tapered 1020 Hi Tensile Steel Legs
Handlebars: 9” X 29” 1020 Hi Tensile Steel With 1° Up Sweep, 12° Back Sweep
Grips: United Jimmy Grips & United Bar Ends
Headset: United Integrated Sealed Bearing
Stem: United 50mm Reach Top Load Stem With Embossed United Logo On Faceplate And Forged Detailing On Sides
Rear Lever: Alloy
Rear Brake: 990
Cranks: 3pc 170mm, Tubular Cromo, 8 Spline, Printed United Logo
Bb: United Sealed Bearing Mid
Sprocket: 28t Steel
Pedals: United Supreme Pc
Chain: X410
Rear Rim: Alloy 36h, Single Wall
Front Rim: Alloy 36h, Aero, Single Wall
Rear Hub: 36h United Supreme Sealed Alloy Cassette Hub With 14mm Axle, Sealed Bearing 9t Driver, 4 Pawl, Ultra Loud Mechanism
Front Hub: 36h Alloy, Sealed Bearing, 10mm Female Axle
Rear Tyre: United In-Direct 20 X 2.10”
Front Tyre: United In-Direct 20 X 2.35”
Seat: United Padded Seat/Post Combo With Custom Sewn Patch On Rear
Seat Post: Integrated With Seat
Seat Clamp: Alloy
